Applications
These CQC approved PUR sheathed cables are used in the Chinese market. They are essential for the connection between an external charging station and the road vehicle. In addition to the power cores for the power supply, there are so-called pilot cores for communication between the road vehicle and the charging electronics. The flame-retardant cables are designed for an operating voltage of 450V and can be operated at a maximum continuous temperature of 90°C. They meet extremely high requirements regarding mechanical strength and electrical safety.
Characteristics
- TPU sheath material for rough everyday use
- Cable structure according to CQC GB / T 33594
- Pilot wires for communication between Road vehicle and charging electronics
- maximum continuous temperature up to 90 °C
- Able to withstand vehicle drive over
- Extremely flexible
- Flame retardant according to EN 60332-1-2
- good resistance to microbes and chemicals
China: Electric vehicle charging cables EV and EYU according to CQC
| Coroflex | CORES | PILOT CORES | CORE | OUTER SHEATH | RESISTANCE (d.c. 20 °C) (max.) | CABLE WEIGHT | ||||
|---|---|---|---|---|---|---|---|---|---|---|
| TYPE NO. | NO. | SIZE | NO. | SIZE | DIAMETER [mm] | DIAMETER [mm] | CONDUCTOR [mΩ/m] | approx. [g/m] | ||
| 8-2800 | 5 x | 2.5 mm² | 1 x | 0.50 mm² | 3.60 | ± 0.2 | 13.30 | ± 0.4 | 7.6 | 229 |
| 8-2800 | 3 x | 2.5 mm² | 1 x | 0.50 mm² | 3.80 | ± 0.2 | 11.30 | ± 0.4 | 7.6 | 174 |
| 8-2800 | 3 x | 2.5 mm² | 1 x | 0.75 mm² | 3.60 | ± 0.2 | 11.30 | ± 0.4 | 7.6 | 157 |
| 8-2800 | 3 x | 6.0 mm² | 1 x | 0.50 mm² | 4.50 | ± 0.2 | 12.90 | ± 0.4 | 3.1 | 282 |
| 8-2800 | 3 x | 6.0 mm² | 1 x | 0.75 mm² | 4.50 | ± 0.2 | 12.90 | ± 0.4 | 3.1 | 282 |
